Bestscope BS-2070 Biological Microscope with Infinite Optional System for Lab
IntroductionBS-2070 series microscopes are high level microscopes which are specially designed for college education, medical and laboratory research. They adopt Infinite Optional system, beautiful structure and ergonomic design. With an innovative Optional and structure design idea, excellent Optio......
Send Inquiry
Product Description
Introduction
BS-2070 series microscopes are high level microscopes which are specially designed for college education, medical and laboratory research. They adopt Infinite Optional system, beautiful structure and ergonomic design. With an innovative Optional and structure design idea, excellent Optional performance and easy to operate system, these biological microscopes make your works enjoyable.
Features
1. Excellent image quality with infinite Optional system.
2. Comfortable operating with ergonomic design.
3. Better illumination with sliding-in centerable condenser, convenient to replace phase contrast and dark field condenser.
4. Advanced design of mechanical stage structure prevents the scratches of users.
Applications
BS-2070 series microscopes are ideal instruments in biological, histological, pathological, bacteriology, immunizations and pharmacy field and can be widely used in medical and sanitary establishments, laboratories, institutes, academic laboratories, colleges and universities.
Specifications
BS-2070 series microscopes are high level microscopes which are specially designed for college education, medical and laboratory research. They adopt Infinite Optional system, beautiful structure and ergonomic design. With an innovative Optional and structure design idea, excellent Optional performance and easy to operate system, these biological microscopes make your works enjoyable.
Features
1. Excellent image quality with infinite Optional system.
2. Comfortable operating with ergonomic design.
3. Better illumination with sliding-in centerable condenser, convenient to replace phase contrast and dark field condenser.
4. Advanced design of mechanical stage structure prevents the scratches of users.
Applications
BS-2070 series microscopes are ideal instruments in biological, histological, pathological, bacteriology, immunizations and pharmacy field and can be widely used in medical and sanitary establishments, laboratories, institutes, academic laboratories, colleges and universities.
Specifications
| Model | BS-2070B | BS-2070T | |
| Optional System | Infinite Optional System | Yes | Yes |
| Viewing Head | Seidentopf Binocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm | Yes | |
| Seidentopf Trinocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm | Yes | ||
| Eyepiece | WF10×/20 | Yes | Yes |
| WF15×/16 | Optional | Optional | |
| Objective | Infinite Plan Achromatic Objective 4×, 10×, 40×, 100× | Yes | Yes |
| Infinite Plan Achromatic Objective 20×, 60× | Optional | Optional | |
| Nosepiece | Backward Quadruple Nosepiece | Yes | Yes |
| Backward Quintuple Nosepiece | Optional | Optional | |
| Focusing | Coaxial Coarse & Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 22mm | Yes | Yes |
| Stage | Rectangular 216×150mm, Cross Travel 78×54mm, Using Low-positioned X/Y Coaxial Control Knob, Can Hold Two Sides | Yes | Yes |
| Condenser | Abbe Condenser NA1.25 with Aperture Diaphragm | Yes | Yes |
| Illumination | LED illumination, Brightness Adjustable | Yes | Yes |
| 12V/20W Halogen Lamp, Brightness Adjustable | Optional | Optional | |
| Optional | Photo Attachment, Video Attachment, Polarization Set, Phase Contrast Kit, Kohler Illumination | Optional | Optional |
| Dimension & G.W. | 38cm*26cm*51cm, 9kg | Yes | Yes |
| Note: Yes Standard Outfit, Optional Standard Optional | |||
Sample Images
