Bestscope BS-5040b Polarizing Microscope with Color Corrected Infinity Optional System
IntroductionThe BS~5040 series transmitted polarizing microscopes are equipped with a smooth, rotating, graduated stage and a set of polarizers that allow observation of all types of transmitted light polarized specimens such as thin sections of minerals, polymers, crystals and particulates. It is e......
Send Inquiry
Product Description
Introduction
The BS~5040 series transmitted polarizing microscopes are equipped with a smooth, rotating, graduated stageand a set of polarizers that allow observation of all types of transmitted light polarized specimens such as thin
sections of minerals, polymers, crystals and particulates. It is equipped with an infinite Optional system, a
comfortable viewing head and a set of Strain~free Infinity Plan Objectives which give a magnification range of
40X 400X. Digital camera can be used together with BS-5040T for image analysis.
Features
1. Color Corrected Infinity Optional System.2. Infinity Strain-free Plan Objectives, ensuring excellent resolution and clarity.
3. Center adjustable nosepiece and center adjustable rotating platform make the operation more accurate and
reliable.
Application area
The BS~5040 series polarizing microscopes are specifically designed for geology, minerals, metallurgy, universityteaching laboratories and other sectors. They also can be used in chemical fiber industry, semiconductor industry
and the pharmaceutical inspection industry.
Sample Images
| Specification | |||
| Model | BS-5040B | ||
| Optional System | Color Corrected Infinity Optional System | Yes | |
| Viewing Head | Seidentopf Binocular Head, Inclined 30°, Rotatable 360°, Interpupilary Distance: 50-75mm. | Yes | |
| Seidentopf Trinocular Head, Inclined 30°, Rotatable 360°, Interpupilary Distance: 50-75mm. Light Distribution: 20:80 | |||
| Eyepiece | WF 10×/18mm | Yes | |
| WF 10×/18mm (Graticule 0.1mm) | Yes | ||
| Objective | Strain-free Infinity Plan Objective | 4× | Yes |
| 10× | Yes | ||
| 20× (S) | Yes | ||
| 40× (S) | Yes | ||
| 60× (S) | Optional | ||
| Nosepiece | Center Adjustable Quadruple Nosepiece | Yes | |
| Analyzing Unit | Rotatable 360°(Module Type, Can Be Locked) | Yes | |
| Bertrand Lens | Inbuilt, Center Adjustable | Yes | |
| Optional Compensator | λ Slip First Class Red | Yes | |
| 1/4λ Slip | Yes | ||
| (I-IV Class) Quartz Wedge | Yes | ||
| Stage | Revolving Round Stage, Rotatable 360°, Center Adjustable, Division 1°, Vernier division 6' | Yes | |
| Polarizing Attached Mechanical Stage | Optional | ||
| Condenser | Abbe N.A. 1.25 Non-stress | Yes | |
| Polarizing Unit | With Scale Rotatable 360°, Can Be Locked | Yes | |
| Illumination | 6V/20W Halogen Lamp | Yes | |
| 6V/30W Halogen Lamp | Optional | ||
| Filter | Blue(Built in) | Yes | |
| Amber | Optional | ||
| Green | Optional | ||
| Neutral | Optional | ||
| C-mount | 1×, 0.47X (Focus adjustable) | ||
| Note: Yes Standard outfits, Optional Optional Accessories. Packing Size: 570mm×275mm×450mm Gross Weight: 8.6 kgs Net Weight: 7.5 kgs | |||
