Cylindrical Round Fresnel Lens
Product DescriptionCylindrical lens are offered in both plano-concave and plano-convex configurations, they are typically used to focus incoming light to a line, or to change the aspect ratio of an image. Cylinder Lenses are available with positive or negative focal lengths, they are used for the op......
Send Inquiry
Product Description
Product DescriptionCylindrical lens are offered in both plano-concave and plano-convex configurations, they are typically used to focus incoming light to a line, or to change the aspect ratio of an image. Cylinder Lenses are available with positive or negative focal lengths, they are used for the optics, lasers, medical science, electronics, tele-communication and others.
Specification:
| Material | N-bk7,H-K9L,Fused Silica,N-SF10,Silicon,CaF2,Sapphire etc. | ||
| Length | 2~300mm | Centration | <3 arc min |
| Height | 2~300mm | Clear Aperture | >90% |
| Radius | >1.5mm | Flatness (per 25mm at 632.8nm) | <1.5Lambda(General) <1/4Lambda(High Precision) |
| Center Thickness | >0.5mm | Irregularity of Fringes | 0.2-0.5 Lambda |
| Focal Length | 3~3000mm | Surface Quality(S/D) | 60/40,40/20 or better |
| Size Tolerance(mm) | +/-0.1mm,+/-0.05mm | Chamfer | <0.25mmx45 degree |
| Center Thichness Tolerance(mm) | +/-0.1mm,+/-0.05mm | Coating | Uncoated,AR,BBAR,Reflective |
| Focal length Tolerance(mm) | ±1% | Design Wavelength | 632.8nm |
